●main configuration of vacuum sintering furnace:

1.furnace door：rotary hinge; manual / automatic lock tight

2.furnace shell：all carbon steel/stainless steel inner/all stainless steel

3.furnace inner liner ：soft carbon felt and hard composite felt / full hard composite felt

4. heater material: static pressure graphite / three-high graphite molding

5.furnace body：vertical type/ horizontal type

6.gas circuit control：volume/mass flow-meter；manual value/automatic value；import/domestic

7.vacuum pumps and vacuum gauges: import / domestic

8. skip: raceway / forklift

9.operation panel：analog screen / touch screen / industrial control machine

10.plc：delta / omron / siemens / mitsubishi

11.temperature control instrument: shimaden /oulu

12. temperature measuring type: infrared optics temperature measuring instrument/ c index number thermocouple (wolfram / mo / ceramic bushing）

13. recorder: paperless recorder / paper recorder; import / domestic

14. electrical element: chint / schneider / siemens /abb

the pics of vertical type sintering furnace:

vertical type:

model parameter		lab usage		production usage
model parameter		nti-sjl-4l	nti-sjl-9l	nti-sjl-57l	nti-sjl-100l	nti-sjl-206l	nti-sjl-339l	nti-sjl-754l	nti-sjl-2260l
working size（d×h）	mm	φ150×250	φ200×300	φ350×600	φ400×800	φ500×1050	φ600×1200	φ800×1500	φ1200×2000
heating type	/	if induction heating
control type	/	thyristor control or igbt control ( optional )
ht zone capacity	l	4	9	57	100	206	339	754	2260
loading weight	g	ht zone capacity × density (g/cm³)×1000 remark：1l=1000cm³
ultimate vacuum	pa	20
if power	kw	60	90	120	180	200	300	500	800
max. working temperature	℃	2500	2500	2500	2500	2500	2500	2500	2500
usual working temperature	℃	2400	2400	2400	2400	2400	2400	2400	2400
temperature unifomity	℃	±10	±10	±10	±10	±10	±10	±10	±10
working environment	/	vacuum or ar, n2 atmosphere protection( micro positive pressure)

horizontal type:

model parameter		lab usage	production usage
model parameter		nti-sml-54w	nti-sml-98w	nti-sml-182w	nti-sml-432w	nti-sml-576w	nti-sml-1280w
working size	mm	300×300×600	350×350×800	450×450×900	520×520×1600	600×600×1600	800×800×2000
heating type	/	if induction heating
control type	/	thyristor control or igbt control ( optional )
ht zone capacity	l	54	98	182	432	576	1280
loading weight	g	ht zone capacity × density (g/cm³)×1000 remark：1l=1000cm³
ultimate vacuum	pa	20
if power	kw	150	200	250	350	500	700
max. working temperature	℃	3000	3000	3000	2900	2900	2900
usual working temperature	℃	2800	2800	2800	2800	2800	2800
temperature unifomity	℃	±10	±10	±10	±10	±15	±15
working environment	/	vacuum or ar, n2 atmosphere protection( micro positive pressure)

configuration:

380v±10%，50hz/60hz 3 phase 5 wire

one control cabinet to one furnace and optional for one to two type or one to four type.

technical feature of vacuum sintering furnace:

1.adopting special furnace inner liner structure and heater arrangement, it has good uniformity of the furnace temperature.

2.adopting special structure for the degreasing chamber, efficiency sealing, completely degreasing and no pollution to the inner element.

3. vacuum sintering furnace has flexible vacuum pumping, vacuum sintering, micro positive pressure sintering, partial pressure sintering, micro positive degreasing, and other functions；

4. adopting the most advanced heat insulation structure and materials, good heat insulation performance of furnace liner, less heat, more than traditional design energy saving 25%.

5.adopting touch screen operation, plc centralized control, simple operation, high reliability.

6. vacuum sintering furnace has the alarm function of ultra-temperature and ultra-voltage, mechanical and automatic for pressure protection action, interlocking functions, high safety equipment.

7.vacuum sintering furnace has remote operation、remote fault diagnosis and remote software upgrades and other function.

8. the hard alloy products sintered by our vacuum sintering furnace can reach to 58hrc of hardness.
