lower power lab usage sintering furnace-凯发体育官方app

 all our furnace can be custom made:

		nti-sjl-4l	nti-sjl-9l	nti-sjl-57l
working size （l×w×h）	mm	150×250	200×300	350×600
heating type	/	induction heating
power control	/	igbt or silicon controlled
max. capacity	l	4	9	57
loading capacity	g	ht area capacity × product’s density(g/cm³)×1000        1l=1000cm³
input voltage	/	380v±10%，50hz/60hz   3 phase 5 wire
equipment structure	/	one power to one or two or four furnace
type	/	vertical
power	kw	60	90	120
frequency	hz	8000	8000	2500
max. temperature	℃	2500	2500	2500
working tem.	℃	2400	2400	2400
tem.uniformity	℃	±10	±10	±10
working environment	/	vacuum or ar、n2  atmospher environment (micro-positive pressure)

feature:

the furnace adopts alumina fiber products insulation, keeping temperature, domestically produced high-quality silicon molybdenum bar heating, high quality corundum tube furnace, the system can pre-pumped vacuum and gas using rotameter control, importing single loop intelligent temperature control instrument control, the equipment has the characteristics of uniform temperature, stable control, fast heating speed, energy saving, high working temperature, long service life and so on, it is an ideal equipment for scientific research.

the furnace making process:

the raw materials suitable for heating:

the packing mode:
