ht electrical heating carbonization furnace

type：resistance furnace

input size：custom made

processed materials：custom made

applications： for materials with high thermal conductivity (pi membrane) vacuum carbonization treatment

leave message

high thermal conductivity vacuum carbonization treatment is the key equipment to produce high performance

heat conductive film, the front door or double door in the front or back, pi membrane carbonizing by this

equipment, with excellent resistance structure and density. it can realize continuous vacuum

carbonization-sintering craft; equipped with decoking system, strengthen the decoking effect, furnace

atmosphere is more stable, easily control product quality, extending the service life of the carbon felt and the

heating material.

model parameter		lab usage	production usage
model parameter		nti-thl-54w	nti-thl-243w	nti-thl-300w	nti-thl-400w	nti-thl-720w	nti-thl-720 nw
working size	mm	300×300×600	450×450×1200	500×500×1200	500×500×1600	600×600×2000	（600-800）×（600-800）×（2000-4000）
control process		thyristor control
heating type	/	resistance heating
ht zone capacity	l	54	243	300	400	720	720 n
loading weight	g	ht zone capacity × density (g/cm³)×1000 remark：1l=1000cm³
ultimate vacuum	pa	20
if power	kw	50	105	120	135	189	189-500
heating zone	zone	1	3	3	3	3	3-6
max. working temperature	℃	1600	1600	1600	1600	1600	1600
usual working temperature	℃	1500	1500	1500	1500	1500	1500
temperature unifomity	℃	±5	±5	±5	±5	±5	±10
working environment	/	vacuum or ar, n2 atmosphere protection( micro positive pressure)

model	nti-thl-400w
max.temperature	1600℃
working tem.	1500℃
input voltage	380v±10%，50hz/60hz
rated power	135 kw
heating area	3 regions
ht area size	540 mm × 540 mm × 1600 mm
effective heating	constant tem.area: 500 mm × 500 mm × 1600 mm
tem.measurement	tungsten rhenium thermocouple（0℃--1700℃）
tem.controlling	shimadne automatic control and high precision adjustable manual control.（accuracy:0.3）
exhaust way	smart or manual for choice.
accuracy	±0.25% tips：up to infrared probe accuracy grade
tem.uniformity	≤±5℃。(after 30min of heating )
inner atmospher	vacuum or ar、n₂atmospher(micro-positive pressure)
alarm system	plc smart pre-alarm、alarm and power supply protection
filtration	4 grades purifing system
cooling	closed inner circulating water cooling/ fbp-2a
purifing	argon gas purifier /gya-4c
ipc	mcgs (tpc1061ti),(delta)plc
vacuum system	side valve type vacuum pumph-150( 1set）、vacuum valve、pipeline and vacuum gauge vacuum degree:20pa
total weight	about 5 tons
