model

st21-sk1

st21-sk2

st21-sk3

paramter

tem.range

600℃～1800℃

800℃～2500℃

1000℃～3000℃

accuracy

value measuring ±1%

repeatability

value measuring ±0.5%

resolution

1℃

emissivity

0.10～1.00 adjustable, step size 0.01

response time

less than 50ms

tem.meas.mode

instantaneous value, maximum value and average value

time interval

1～30s,  step size 1s

optics parameter

working band

1.0um

distance coefficient

400:1

aiming mode

telescope aiming

electrical

power

24v dc±10%  100ma

output

4～20ma and rs485

environment

working tem.

-10℃～ 60℃, cooling with the water to 150℃

storage tem.

-20℃～80℃

relative humidity

10%～90%rh non condensing

physics

shell material

stainless steel

size

167mm×ф50mm

weight

600g
