cooling tower fbp-6a

type:other related products

input size:2500×1200×2600

leave message
  • overview
  • specifications
  • features
model
fbp-6a
series no
name
unit/ value
1
working flow amount
26-45m3/h
2
cooling amount
180000kcal/h
3
in and out pipe diameter
dn65
4
red copper pipe
φ16mm   t0.6mm
5
spraying pump parameter
12.5m  25m3/h  1.5kw
6
water pump
38m  43.5m3/h   7.5kw
7
working pressure
0.3mpa
8
draught fan parameter
13000m3/h   1.1kw×2 set
9
draught diameter
φ750
10
rated voltage
380v-50hz
11
net weight(empty chamber situation)
1400kg
12
outer size（mm）
2500×1200×2600
