ain ceramic 2200c vacuum sintering furnace

type:resistance furnace

input size:custom made

processed materials:304,graphite crucibles and so on

applications:for high temperature refractory materials' carbonizing

leave message

overview
specifications
features

horizontal vacuum carbonization furnace

●application:
application for thermally conductive film carbonization, glass-fiber carbonization, ain powder, ain film, ain ceramic, organic matter carbonization, powder carbonization and such as field, can be combined with the use of the graphite furnace, used in new materials, carbon and carbon materials, special ceramics industry.

qq图片20170929112318

qq图片20171006093859

the main technical parameters:

model parameter		lab usage	production usage
model parameter		nti-dzl-54w	nti-dzl-243w	nti-dzl-300w	nti-dzl-400w	nti-dzl-720w	nti-dzl-720 nw
working size	mm	300×300×600	450×450×1200	500×500×1200	500×500×1600	600×600×2000	（600-800）×（600-800）×（2000-4000）
control process		thyristor control
heating type	/	resistance heating
ht zone capacity	l	54	243	300	400	720	720 n
loading weight	g	ht zone capacity × density (g/cm³)×1000 remark：1l=1000cm³
ultimate vacuum	pa	20
if power	kw	50	105	120	135	189	189-500
heating zone	zone	1	3	3	3	3	3-6
max. working temperature	℃	2300	2300	2300	2300	2300	2300
usual working temperature	℃	2200	2200	2200	2200	2200	2200
temperature unifomity	℃	±5	±5	±5	±5	±5	±10
working environment	/	vacuum or ar, n2 atmosphere protection( micro positive pressure)

●feature:

1. the high temperature furnace body is within 2200 degrees celsius, and can be compatible with various carbonization and sintering craft. this equipment adopts the front door or front and back double doors, with excellent resistance structure and density. the continuous vacuum carbonization sintering craft can be realized; the system is provided with a decoking system, the effect of the decoking is enhanced, the atmosphere in the furnace is more stable, the product quality is easy to be controlled, and the service life of the carbon felt and heating material is prolonged.

2.adopting resistive heating, the service life of the graphite tube is long, excellent heating efficiency, convenient maintain. uniform heating, reliable insulation and temperature measuring system, advanced furnace hearth design concept, reasonable heating structure, high quality materials to ensure vacuum furnace temperature uniformity. adopt the domestic and international brand temperature measuring elements to ensure the accuracy of the temperature measurement. the advanced temperature control system, imported digital display intelligent temperature control meter, plc and practical data communication, automatic high precision finish temperature measure and control, the system can rise temperature according to the given curve, and can store 4 sections in total 40 segments different heating process curve. single room, horizontal structure, equipment layout is compact and reasonable, covers an area of small.

3. advanced automation control, plc water, electricity and gas comprehensive automatic control and protection system, plc safety chain, with sound and light alarm function for over temperature, sensor fault, water-pressure, furnace overpressure, water flow, water temperature too high. environmental protection, energy saving, non purification of the essence of the vacuum exhaust gas, effective protection of the normal operation of the vacuum pump and a good effect of decoking.

4. the cooling of the furnace body is cooled by natural cooling, and the low temperature section can be cooled by charging a positive pressure inert gas to increase the cooling speed. exclusive design of the furnace body explosion-proof valve, safe and reliable.
